FAG S6304-2RSR-FD

FAG S6304-2RSR-FD
FAG S6304-2RSR-FD rulman resim 1
FAG S6304-2RSR-FD rulman resim 2
FAG S6304-2RSR-FD rulman resim 3
FAG S6304-2RSR-FD rulman resim 4
Price: 42.37 $
Specifications
Brand FAG
Item Number S6304-2RSR-FD FAG
Manufacturer Part Number 0947141500000
Also known as W6304-2RS1/VP311
EAN 4054372432873
Category Stainless Steel Ball Bearings
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 52
Width (B) MM 15
Inner (d) Inch 0.7874
Outer (D) Inch 2.0472
Width (B) Inch 0.5906
Weight (kg) 0.144 kg
Product Properties
Bore C - Cylindrical Bore
Seal 2RS - Rubber Seal on Two Sides
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Lubrication Food Grease
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 15
Radial Static Load Rating C0r (N) 6270
Radial Dynamic Load Rating Cr (N) 13500
Limiting speed (n G) 5900
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description main dimensions to DIN 625-1, corrosion resistant materials, lip seals on both sides, food-grade grease, FD design
Suffix description
2RSR Rubber Seals At Each Side Of The Bearing
FD Bearing Designed For Food Industry. Significantly Higher Corrosion And Media Resistance
