FAG QJ311-XL-MPA-C3

FAG QJ311-XL-MPA-C3
FAG QJ311-XL-MPA-C3 rulman resim 1
FAG QJ311-XL-MPA-C3 rulman resim 2
FAG QJ311-XL-MPA-C3 rulman resim 3
FAG QJ311-XL-MPA-C3 rulman resim 4
Price: 159.85 $
Specifications
Brand FAG
Item Number QJ311-XL-MPA-C3 FAG
Manufacturer Part Number 0167425590030
Also known as QJ311-MPA-C3
EAN 4012801268127
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 55
Outer (D) MM 120
Width (B) MM 29
Inner (d) Inch 2.1654
Outer (D) Inch 4.7244
Width (B) Inch 1.1417
Weight (kg) 1.675 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 29
Radial Static Load Rating C0r (N) 108000
Radial Dynamic Load Rating Cr (N) 133000
Basic static load rating, radial (C 0r) "108000.0000"
Limiting speed (n G) 11400
Reference speed (n u03d1r) 5000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ3..-XL-MPA, inner ring split
Suffix description
XL X-Life
MPA Solid Brass Cage
C3 Internal Clearance Larger Than Normal
