FAG 6311-C-Z-C3

FAG 6311-C-Z-C3
FAG 6311-C-Z-C3 rulman resim 1
FAG 6311-C-Z-C3 rulman resim 2
FAG 6311-C-Z-C3 rulman resim 3
FAG 6311-C-Z-C3 rulman resim 4
Price: 41.22 $
Specifications
Brand FAG
Item Number 6311-C-Z-C3 FAG
Manufacturer Part Number 0890320800030
Also known as 6311-Z-C3
EAN 4054369499438
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 55
Outer (D) MM 120
Width (B) MM 29
Inner (d) Inch 2.1654
Outer (D) Inch 4.7244
Width (B) Inch 1.1417
Weight (kg) 1.38 kg
Product Properties
Bore C - Cylindrical Bore
Seal Z - Steel Seal on One Side
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 29
Radial Static Load Rating C0r (N) 47500
Radial Dynamic Load Rating Cr (N) 83000
Basic static load rating, radial (C 0r) "47500.0000"
Limiting speed (n G) 8500
Reference speed (n u03d1r) 7800
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 63..-C-Z, single row, cf. DIN 625-1
Suffix description
C Deep Groove Ball Bearings Of Generation C, Modified Internal Construction
Z Shield Of Pressed Sheet Steel On One Side Of The Bearing
C3 Internal Clearance Larger Than Normal
