FAG 6311-M-J20AA-C3

FAG 6311-M-J20AA-C3
FAG 6311-M-J20AA-C3 rulman resim 1
FAG 6311-M-J20AA-C3 rulman resim 2
FAG 6311-M-J20AA-C3 rulman resim 3
FAG 6311-M-J20AA-C3 rulman resim 4
Price: 439.60 $
Specifications
Brand FAG
Item Number 6311-M-J20AA-C3 FAG
Manufacturer Part Number 0764838860030
Also known as 6311M/C3VL0241
EAN 4054364792145
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 55
Outer (D) MM 120
Width (B) MM 29
Inner (d) Inch 2.1654
Outer (D) Inch 4.7244
Width (B) Inch 1.1417
Weight (kg) 1.66 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Breakdown Voltage 1000v
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 29
Radial Static Load Rating C0r (N) 47500
Radial Dynamic Load Rating Cr (N) 83000
Basic static load rating, radial (C 0r) "47500.0000"
Limiting speed (n G) 11000
Reference speed (n u03d1r) 7100
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 63..-M-J20AA, single row, cf. DIN 625-1
Suffix description
M Solid Brass Cage, Ball-Guided
J20AA Coating Which Consists Of Oxide Ceramic, It Is Applied By Plasma Spraying And Then Sealed With Synthetic Resin. Speciality Humid Environments
C3 Internal Clearance Larger Than Normal
