FAG QJ214-XL-N2-MPA

FAG QJ214-XL-N2-MPA
FAG QJ214-XL-N2-MPA rulman resim 1
FAG QJ214-XL-N2-MPA rulman resim 2
FAG QJ214-XL-N2-MPA rulman resim 3
FAG QJ214-XL-N2-MPA rulman resim 4
FAG QJ214-XL-N2-MPA rulman resim 5
Price: 170.48 $
Specifications
Brand FAG
Item Number QJ214-XL-N2-MPA FAG
Manufacturer Part Number 0392894510000
Also known as QJ214-N2-MPA
EAN 4012802343809
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 70
Outer (D) MM 125
Width (B) MM 24
Inner (d) Inch 2.7559
Outer (D) Inch 4.9213
Width (B) Inch 0.9449
Weight (kg) 1.3 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 24
Radial Static Load Rating C0r (N) 114000
Radial Dynamic Load Rating Cr (N) 118000
Basic static load rating, radial (C 0r) "114000.0000"
Limiting speed (n G) 10700
Reference speed (n u03d1r) 4700
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-XL-N2-MPA, inner ring split
Suffix description
XL X-Life
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
