FAG HC6214-M-P6-C3
Price: 1,345.97 $
Specifications
| Brand | FAG |
| Item Number | HC6214-M-P6-C3 FAG |
| Manufacturer Part Number | 0388996200030 |
| EAN | 4026677589101 |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 70 |
| Outer (D) MM | 125 |
| Width (B) MM | 24 |
| Inner (d) Inch | 2.7559 |
| Outer (D) Inch | 4.9213 |
| Width (B) Inch | 0.9449 |
| Weight (kg) | 1.232 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | P6 Precision (Higher than Standard) |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| Width (b) mm | 24 |
| Radial Static Load Rating C0r (N) | 42000 |
| Radial Dynamic Load Rating Cr (N) | 66000 |
| Basic static load rating, radial (C 0r) | "42000.0000" |
| Limiting speed (n G) | 12800 |
| Reference speed (n u03d1r) | 6800 |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Deep groove ball bearing HC62..-M, single row, cf. DIN 625-1 |
| M | Solid Brass Cage, Ball-Guided |
| P6 | Dimensional And Running Accuracy To ISO Tolerance Class 6 (Better Than Normal) |
| C3 | Internal Clearance Larger Than Normal |
