FAG 6214-Z

FAG 6214-Z
FAG 6214-Z rulman resim 1
FAG 6214-Z rulman resim 2
FAG 6214-Z rulman resim 3
FAG 6214-Z rulman resim 4
Price: 41.98 $
Specifications
Brand FAG
Item Number 6214-Z FAG
Manufacturer Part Number 0191049950000
Also known as 6214-C-Z
EAN 4012801203395
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 70
Outer (D) MM 125
Width (B) MM 24
Inner (d) Inch 2.7559
Outer (D) Inch 4.9213
Width (B) Inch 0.9449
Weight (kg) 1.08 kg
Product Properties
Bore C - Cylindrical Bore
Seal Z - Steel Seal on One Side
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 24
Radial Static Load Rating C0r (N) 44000
Radial Dynamic Load Rating Cr (N) 66000
Basic static load rating, radial (C 0r) "44000.0000"
Limiting speed (n G) 8200
Reference speed (n u03d1r) 6100
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 62..-Z, single row, cf. DIN 625-1
Suffix description
Z Shield Of Pressed Sheet Steel On One Side Of The Bearing
