FAG QJ214-XL-MPA-C3

FAG QJ214-XL-MPA-C3
FAG QJ214-XL-MPA-C3 rulman resim 1
FAG QJ214-XL-MPA-C3 rulman resim 2
FAG QJ214-XL-MPA-C3 rulman resim 3
FAG QJ214-XL-MPA-C3 rulman resim 4
FAG QJ214-XL-MPA-C3 rulman resim 5
FAG QJ214-XL-MPA-C3 rulman resim 6
Price: 158.11 $
Specifications
Brand FAG
Item Number QJ214-XL-MPA-C3 FAG
Manufacturer Part Number 0167423110030
Also known as QJ214-MPA-C3
EAN 4012801157681
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 70
Outer (D) MM 125
Width (B) MM 24
Inner (d) Inch 2.7559
Outer (D) Inch 4.9213
Width (B) Inch 0.9449
Weight (kg) 1.3 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 24
Radial Static Load Rating C0r (N) 114000
Radial Dynamic Load Rating Cr (N) 118000
Basic static load rating, radial (C 0r) "114000.0000"
Limiting speed (n G) 10700
Reference speed (n u03d1r) 4700
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-XL-MPA, inner ring split
Suffix description
XL X-Life
MPA Solid Brass Cage
C3 Internal Clearance Larger Than Normal
