FAG QJ206-XL-N2-MPA-T42B

FAG QJ206-XL-N2-MPA-T42B
FAG QJ206-XL-N2-MPA-T42B rulman resim 1
FAG QJ206-XL-N2-MPA-T42B rulman resim 2
FAG QJ206-XL-N2-MPA-T42B rulman resim 3
FAG QJ206-XL-N2-MPA-T42B rulman resim 4
FAG QJ206-XL-N2-MPA-T42B rulman resim 5
Price: 62.55 $
Specifications
Brand FAG
Item Number QJ206-XL-N2-MPA-T42B FAG
Manufacturer Part Number 0389052994380
Also known as QJ206-N2-MPA-T42B
EAN 4026677656094
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 62
Width (B) MM 16
Inner (d) Inch 1.1811
Outer (D) Inch 2.4409
Width (B) Inch 0.6299
Weight (kg) 0.24 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play Cn Normal Internal Play
Precision Special Axial Clearance
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 16
Radial Static Load Rating C0r (N) 27500
Radial Dynamic Load Rating Cr (N) 37500
Basic static load rating, radial (C 0r) "27500.0000"
Limiting speed (n G) 23200
Reference speed (n u03d1r) 10200
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-XL-N2-MPA, inner ring split
Suffix description
XL X-Life
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
T42B Four Point Bearings With Special Axial Clearance
