FAG 6206-2Z-L100-C3

FAG 6206-2Z-L100-C3
FAG 6206-2Z-L100-C3 rulman resim 1
FAG 6206-2Z-L100-C3 rulman resim 2
FAG 6206-2Z-L100-C3 rulman resim 3
FAG 6206-2Z-L100-C3 rulman resim 4
Price: 11.03 $
Specifications
Brand FAG
Item Number 6206-2Z-L100-C3 FAG
Manufacturer Part Number 0388967880030
Also known as 6206-C-2Z-L100-C3
EAN 4026677756442
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 62
Width (B) MM 16
Inner (d) Inch 1.1811
Outer (D) Inch 2.4409
Width (B) Inch 0.6299
Weight (kg) 0.201 kg
Product Properties
Bore C - Cylindrical Bore
Seal ZZ/2Z - Steel Seal on Two Sides
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Higher and Lower Temperature Grease
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 16
Radial Static Load Rating C0r (N) 11300
Radial Dynamic Load Rating Cr (N) 20700
Limiting speed (n G) 13800
Reference speed (n u03d1r) 12000
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 62..-2Z, single row, cf. DIN 625-1
Suffix description
2Z Non-Contact Sealing Shield On Both Sides (Sheet Metal Gap Seal)
L100 High/Low Temperature Grease -40ºC/+160ºC
C3 Internal Clearance Larger Than Normal
