FAG 6206-C-2HRS-L100-C3
Price: 11.50 $
Specifications
| Brand | FAG |
| Item Number | 6206-C-2HRS-L100-C3 FAG |
| Manufacturer Part Number | 0956625370030 |
| Also known as |
6206-2HRS-L100-C3 |
| EAN | 4064327005571 |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 30 |
| Outer (D) MM | 62 |
| Width (B) MM | 16 |
| Inner (d) Inch | 1.1811 |
| Outer (D) Inch | 2.4409 |
| Width (B) Inch | 0.6299 |
| Weight (kg) | 0.192 kg |
| Bore | C - Cylindrical Bore |
| Seal | 2RH - High Speed Low Friction Seal on Two Sides |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| Radial Static Load Rating C0r (N) | 11300 |
| Radial Dynamic Load Rating Cr (N) | 20800 |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Deep groove ball bearing 62..-C-2HRS, single row, cf. DIN 625-1 |
| C | Deep Groove Ball Bearings Of Generation C, Modified Internal Construction |
| 2HRS | Lip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal |
| L100 | High/Low Temperature Grease -40ºC/+160ºC |
| C3 | Internal Clearance Larger Than Normal |
