FAG NUP310-E-XL-MPAX-C3 Image 5
Visual product photo and picture of the product.
Price: 162.91 $
Specifications
Weight and Dimensions
| Inner (d) MM |
50 |
| Outer (D) MM |
110 |
| Width (B) MM |
27 |
| Inner (d) Inch |
1.9685 |
| Outer (D) Inch |
4.3307 |
| Width (B) Inch |
1.063 |
| Weight (kg) |
1.38 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
27 |
| Radial Static Load Rating C0r (N) |
114000 |
| Radial Dynamic Load Rating Cr (N) |
131000 |
| Basic static load rating, radial (C 0r) |
"114000.0000" |
| Limiting speed (n G) |
11600 |
| Reference speed (n u03d1r) |
6000 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
| Medias description |
Cylindrical roller bearing NUP..-E-XL-MPAX, with cage, single row, locating bearing, 2 ribs on outer ring, 1 rib on inner ring, rib washer internal, type NUP |
Suffix description
| E |
Increased Load Capacity |
| XL |
X-Life |
| MPAX |
Rib-Guided Single-Piece Solid Brass Cage Is A Further Development Of FAG Cage Types MPA And MP1A And Will Replace These Types Successively. It Has Greater Durability With Regard To Shock Loads And Vibrations Than It's Predecessors And It's Especially Well Suited For Applications Involving High Loads |
| C3 |
Internal Clearance Larger Than Normal |
