FAG NUP310-E-XL-MPAX-C3

FAG NUP310-E-XL-MPAX-C3
FAG NUP310-E-XL-MPAX-C3 rulman resim 1
FAG NUP310-E-XL-MPAX-C3 rulman resim 2
FAG NUP310-E-XL-MPAX-C3 rulman resim 3
FAG NUP310-E-XL-MPAX-C3 rulman resim 4
FAG NUP310-E-XL-MPAX-C3 rulman resim 5
FAG NUP310-E-XL-MPAX-C3 rulman resim 6
FAG NUP310-E-XL-MPAX-C3 rulman resim 7
Price: 162.91 $
Specifications
Brand FAG
Item Number NUP310-E-XL-MPAX-C3 FAG
Also known as NUP310-E-MPAX-C3
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 110
Width (B) MM 27
Inner (d) Inch 1.9685
Outer (D) Inch 4.3307
Width (B) Inch 1.063
Weight (kg) 1.38 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 27
Radial Static Load Rating C0r (N) 114000
Radial Dynamic Load Rating Cr (N) 131000
Basic static load rating, radial (C 0r) "114000.0000"
Limiting speed (n G) 11600
Reference speed (n u03d1r) 6000
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NUP..-E-XL-MPAX, with cage, single row, locating bearing, 2 ribs on outer ring, 1 rib on inner ring, rib washer internal, type NUP
Suffix description
E Increased Load Capacity
XL X-Life
MPAX Rib-Guided Single-Piece Solid Brass Cage Is A Further Development Of FAG Cage Types MPA And MP1A And Will Replace These Types Successively. It Has Greater Durability With Regard To Shock Loads And Vibrations Than It's Predecessors And It's Especially Well Suited For Applications Involving High Loads
C3 Internal Clearance Larger Than Normal
