FAG 6310-C-Z-HRS-L100-C3

FAG 6310-C-Z-HRS-L100-C3
FAG 6310-C-Z-HRS-L100-C3 rulman resim 1
FAG 6310-C-Z-HRS-L100-C3 rulman resim 2
FAG 6310-C-Z-HRS-L100-C3 rulman resim 3
Price: 48.91 $
Specifications
Brand FAG
Item Number 6310-C-Z-HRS-L100-C3 FAG
Manufacturer Part Number 0890275400030
Also known as 6310-Z-HRS-L100-C3
EAN 4064327742421
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 110
Width (B) MM 27
Inner (d) Inch 1.9685
Outer (D) Inch 4.3307
Width (B) Inch 1.063
Weight (kg) 1.06 kg
Product Properties
Bore C - Cylindrical Bore
Seal 2RZ - Rubber and Steel Seal
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Higher and Lower Temperature Grease
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 27
Basic static load rating, radial (C 0r) 38000
Limiting speed (n G) 5800
Suffix description
C Deep Groove Ball Bearings Of Generation C, Modified Internal Construction
Z Shield Of Pressed Sheet Steel On One Side Of The Bearing
HRS Lip Seal On One Side Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal
L100 High/Low Temperature Grease -40ºC/+160ºC
C3 Internal Clearance Larger Than Normal
