FAG NUP206-E-XL-M1

FAG NUP206-E-XL-M1
FAG NUP206-E-XL-M1 rulman resim 1
FAG NUP206-E-XL-M1 rulman resim 2
FAG NUP206-E-XL-M1 rulman resim 3
FAG NUP206-E-XL-M1 rulman resim 4
Price: 80.15 $
Specifications
Brand FAG
Item Number NUP206-E-XL-M1 FAG
Manufacturer Part Number 0384545990000
Also known as NUP206-E-M1
EAN 4026677132383
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 62
Width (B) MM 16
Inner (d) Inch 1.1811
Outer (D) Inch 2.4409
Width (B) Inch 0.6299
Weight (kg) 0.211 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 16
Radial Static Load Rating C0r (N) 37500
Radial Dynamic Load Rating Cr (N) 46000
Basic static load rating, radial (C 0r) "37500.0000"
Limiting speed (n G) 21200
Reference speed (n u03d1r) 9600
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NUP..-E-XL-M1, with cage, single row, locating bearing, 2 ribs on outer ring, 1 rib on inner ring, rib washer internal, type NUP
Suffix description
E Increased Load Capacity
XL X-Life
M1 Solid Brass Cage, Two Piece, Roller Guided
