FAG NU311-E-XL-TVP2-C3

FAG NU311-E-XL-TVP2-C3
FAG NU311-E-XL-TVP2-C3 rulman resim 1
FAG NU311-E-XL-TVP2-C3 rulman resim 2
FAG NU311-E-XL-TVP2-C3 rulman resim 3
FAG NU311-E-XL-TVP2-C3 rulman resim 4
Price: 74.71 $
Specifications
Brand FAG
Item Number NU311-E-XL-TVP2-C3 FAG
Manufacturer Part Number 0167399220030
Also known as NU311-E-TVP2-C3
EAN 4012801022873
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 55
Outer (D) MM 120
Width (B) MM 29
Inner (d) Inch 2.1654
Outer (D) Inch 4.7244
Width (B) Inch 1.1417
Weight (kg) 1.48 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type P - Plastic Molded Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 29
Radial Static Load Rating C0r (N) 139000
Radial Dynamic Load Rating Cr (N) 159000
Basic static load rating, radial (C 0r) "139000.0000"
Limiting speed (n G) 8000
Reference speed (n u03d1r) 5500
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NU..-E-XL-TVP2, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU
Suffix description
E Increased Load Capacity
XL X-Life
TVP2 Solid Window Cage Made From Glass Fibre Reinforced Polyamide PA66. Roller Riding
C3 Internal Clearance Larger Than Normal
