FAG NU309-E-XL-M1-F1-C4

FAG NU309-E-XL-M1-F1-C4
FAG NU309-E-XL-M1-F1-C4 rulman resim 1
FAG NU309-E-XL-M1-F1-C4 rulman resim 2
FAG NU309-E-XL-M1-F1-C4 rulman resim 3
FAG NU309-E-XL-M1-F1-C4 rulman resim 4
FAG NU309-E-XL-M1-F1-C4 rulman resim 5
Price: 150.97 $
Specifications
Brand FAG
Item Number NU309-E-XL-M1-F1-C4 FAG
Manufacturer Part Number 0390240320040
Also known as NU309-E-M1-F1-C4
EAN 4012801975247
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 100
Width (B) MM 25
Inner (d) Inch 1.7717
Outer (D) Inch 3.937
Width (B) Inch 0.9843
Weight (kg) 0.955 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Bearings for Traction Motors
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 25
Basic static load rating, radial (C 0r) 99000
Limiting speed (n G) 12800
Reference speed (n u03d1r) 6400
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Suffix description
E Increased Load Capacity
XL X-Life
M1 Solid Brass Cage, Two Piece, Roller Guided
F1 FAG Manufacturing And Inspection Specification For Cylindrical Roller Bearings In Traction Motors Which Considers, Among Others, The Requirements According To Din 43283 "Cylindrical Roller Bearings For Electric Traction"
C4 Bearing Internal Clearance Greater Than C3
