FAG 6309-M-C3

FAG 6309-M-C3
FAG 6309-M-C3 rulman resim 1
FAG 6309-M-C3 rulman resim 2
FAG 6309-M-C3 rulman resim 3
Price: 116.68 $
Specifications
Brand FAG
Item Number 6309-M-C3 FAG
Manufacturer Part Number 0191096360030
Also known as 6309-C-M-C3
EAN 4012801165419
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 100
Width (B) MM 25
Inner (d) Inch 1.7717
Outer (D) Inch 3.937
Width (B) Inch 0.9843
Weight (kg) 1.02 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 25
Radial Static Load Rating C0r (N) 31500
Radial Dynamic Load Rating Cr (N) 56000
Basic static load rating, radial (C 0r) "31500.0000"
Limiting speed (n G) 12400
Reference speed (n u03d1r) 8200
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 63..-M, single row, cf. DIN 625-1
Suffix description
M Solid Brass Cage, Ball-Guided
C3 Internal Clearance Larger Than Normal
