FAG 6309-C-C4

FAG 6309-C-C4
FAG 6309-C-C4 rulman resim 1
FAG 6309-C-C4 rulman resim 2
FAG 6309-C-C4 rulman resim 3
FAG 6309-C-C4 rulman resim 4
Price: 30.16 $
Specifications
Brand FAG
Item Number 6309-C-C4 FAG
Manufacturer Part Number 0850058860040
EAN 4054372455230
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 100
Width (B) MM 25
Inner (d) Inch 1.7717
Outer (D) Inch 3.937
Width (B) Inch 0.9843
Weight (kg) 0.839 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 25
Radial Static Load Rating C0r (N) 31500
Radial Dynamic Load Rating Cr (N) 58000
Basic static load rating, radial (C 0r) "31500.0000"
Limiting speed (n G) 10500
Reference speed (n u03d1r) 9100
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearings 63..-C, modified internal construction (Generation C), main dimensions to DIN 625-1
Suffix description
C Deep Groove Ball Bearings Of Generation C, Modified Internal Construction
C4 Bearing Internal Clearance Greater Than C3
