FAG NU206-E-XL-M1A-S1-C3

FAG NU206-E-XL-M1A-S1-C3
FAG NU206-E-XL-M1A-S1-C3 rulman resim 1
FAG NU206-E-XL-M1A-S1-C3 rulman resim 2
FAG NU206-E-XL-M1A-S1-C3 rulman resim 3
Price: 78.14 $
Specifications
Brand FAG
Item Number NU206-E-XL-M1A-S1-C3 FAG
Manufacturer Part Number 0192383630030
Also known as NU206-E-M1A-S1-C3
EAN 4026677827876
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 62
Width (B) MM 16
Inner (d) Inch 1.1811
Outer (D) Inch 2.4409
Width (B) Inch 0.6299
Weight (kg) 0.227 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization S1 - Temperatures up to 200 °C
Data from Schaeffler (medias)
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Suffix description
E Increased Load Capacity
XL X-Life
M1A Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring
S1 Bearing Rings Or Washers Dimensionally Stabilized For Use At Operating Temperatures Up To +200°C (392°F)
C3 Internal Clearance Larger Than Normal
