FAG NN3030-AS-M-SP

FAG NN3030-AS-M-SP
FAG NN3030-AS-M-SP rulman resim 1
FAG NN3030-AS-M-SP rulman resim 2
FAG NN3030-AS-M-SP rulman resim 3
FAG NN3030-AS-M-SP rulman resim 4
FAG NN3030-AS-M-SP rulman resim 5
Price: 1,415.49 $
Specifications
Brand FAG
Item Number NN3030-AS-M-SP FAG
Manufacturer Part Number 0384544910000
EAN 4012801581691
Category Cylindrical Roller Bearing Double Row
Weight and Dimensions
Inner (d) MM 150
Outer (D) MM 225
Width (B) MM 56
Inner (d) Inch 5.9055
Outer (D) Inch 8.8583
Width (B) Inch 2.2047
Weight (kg) 7.88 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision SP - Precision Higher than P4S
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 56
Radial Static Load Rating C0r (N) 590000
Radial Dynamic Load Rating Cr (N) 335000
Basic static load rating, radial (C 0r) "590000.0000"
Fatigue load limit, radial (C ur) 73000
Limiting speed for grease lubrication (n G Grease) 3650
Limiting speed for oil lubrication (n G Oil) 4250
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NN..-AS-M-SP, with cage, two-row, non-locating bearing, 0 ribs on outer ring (smooth), 3 ribs on inner ring, type NN
Suffix description
A Cylindrical Roller Bearings, Parts Interchangeable
S Lubrication Groove And Three Holes In Bearing Outer Ring
M Solid Brass Cage, Roller Guided
SP Super Precision Specification, Tolerance Class SP, Radial Clearance C1
