FAG 23030-E1A-XL-K-M-C2

FAG 23030-E1A-XL-K-M-C2
FAG 23030-E1A-XL-K-M-C2 rulman resim 1
FAG 23030-E1A-XL-K-M-C2 rulman resim 2
FAG 23030-E1A-XL-K-M-C2 rulman resim 3
FAG 23030-E1A-XL-K-M-C2 rulman resim 4
FAG 23030-E1A-XL-K-M-C2 rulman resim 5
Price: 530.99 $
Specifications
Brand FAG
Item Number 23030-E1A-XL-K-M-C2 FAG
Manufacturer Part Number 0190252380020
Also known as 23030-E1A-K-M-C2
EAN 4026677882103
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 150
Outer (D) MM 225
Width (B) MM 56
Inner (d) Inch 5.9055
Outer (D) Inch 8.8583
Width (B) Inch 2.2047
Weight (kg) 7.48 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type M - Brass Cage
Radial Internal Play C2 Internal Play (Less than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 56
Radial Static Load Rating C0r (N) 880000
Radial Dynamic Load Rating Cr (N) 630000
Basic static load rating, radial (C 0r) "880000.0000"
Limiting speed (n G) 3250
Reference speed (n u03d1r) 2210
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 230..-E1A-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
