FAG 23030-E1-XL-TVPB-C3

FAG 23030-E1-XL-TVPB-C3
FAG 23030-E1-XL-TVPB-C3 rulman resim 1
FAG 23030-E1-XL-TVPB-C3 rulman resim 2
FAG 23030-E1-XL-TVPB-C3 rulman resim 3
FAG 23030-E1-XL-TVPB-C3 rulman resim 4
FAG 23030-E1-XL-TVPB-C3 rulman resim 5
Price: 372.35 $
Specifications
Brand FAG
Item Number 23030-E1-XL-TVPB-C3 FAG
Manufacturer Part Number 0190010960030
Also known as 23030-E1-TVPB-C3
EAN 4026677827838
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 150
Outer (D) MM 225
Width (B) MM 56
Inner (d) Inch 5.9055
Outer (D) Inch 8.8583
Width (B) Inch 2.2047
Weight (kg) 7.63 kg
Product Properties
Bore C - Cylindrical Bore
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 56
Radial Static Load Rating C0r (N) 880000
Radial Dynamic Load Rating Cr (N) 630000
Limiting speed (n G) 3250
Reference speed (n u03d1r) 2210
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 230..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
C3 Internal Clearance Larger Than Normal
