FAG NN3030-AS-K-M-SP-J15Q

FAG NN3030-AS-K-M-SP-J15Q
FAG NN3030-AS-K-M-SP-J15Q rulman resim 1
Price: 1,435.61 $
Specifications
Brand FAG
Item Number NN3030-AS-K-M-SP-J15Q FAG
Manufacturer Part Number 0192313934300
EAN 4012801581707
Category Cylindrical Roller Bearing Double Row
Weight and Dimensions
Inner (d) MM 150
Outer (D) MM 225
Width (B) MM 56
Inner (d) Inch 5.9055
Outer (D) Inch 8.8583
Width (B) Inch 2.2047
Weight (kg) 7.4 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision SP - Precision Higher than P4S
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 56
Basic static load rating, radial (C 0r) 590000
Fatigue load limit, radial (C ur) 73000
Limiting speed for grease lubrication (n G Grease) 3650
Limiting speed for oil lubrication (n G Oil) 4250
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Suffix description
A Cylindrical Roller Bearings, Parts Interchangeable
S Lubrication Groove And Three Holes In Bearing Outer Ring
K Tapered Bore, Taper 1:12
M Solid Brass Cage, Roller Guided
SP Super Precision Specification, Tolerance Class SP, Radial Clearance C1
J15Q Marking Specifications Of Measured Values
