FAG NJ309-E-XL-TVP2-C4

FAG NJ309-E-XL-TVP2-C4
FAG NJ309-E-XL-TVP2-C4 rulman resim 1
FAG NJ309-E-XL-TVP2-C4 rulman resim 2
FAG NJ309-E-XL-TVP2-C4 rulman resim 3
FAG NJ309-E-XL-TVP2-C4 rulman resim 4
FAG NJ309-E-XL-TVP2-C4 rulman resim 5
FAG NJ309-E-XL-TVP2-C4 rulman resim 6
FAG NJ309-E-XL-TVP2-C4 rulman resim 7
Price: 78.05 $
Specifications
Brand FAG
Item Number NJ309-E-XL-TVP2-C4 FAG
Manufacturer Part Number 0167362650040
Also known as NJ309-E-TVP2-C4
EAN 4012801384278
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 100
Width (B) MM 25
Inner (d) Inch 1.7717
Outer (D) Inch 3.937
Width (B) Inch 0.9843
Weight (kg) 0.895 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type P - Plastic Molded Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 25
Radial Static Load Rating C0r (N) 99000
Radial Dynamic Load Rating Cr (N) 116000
Basic static load rating, radial (C 0r) "99000.0000"
Limiting speed (n G) 8500
Reference speed (n u03d1r) 6400
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NJ..-E-XL-TVP2, with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ
Suffix description
E Increased Load Capacity
XL X-Life
TVP2 Solid Window Cage Made From Glass Fibre Reinforced Polyamide PA66. Roller Riding
C4 Bearing Internal Clearance Greater Than C3
