FAG N206-E-XL-TVP2

FAG N206-E-XL-TVP2
FAG N206-E-XL-TVP2 rulman resim 1
FAG N206-E-XL-TVP2 rulman resim 2
FAG N206-E-XL-TVP2 rulman resim 3
FAG N206-E-XL-TVP2 rulman resim 4
FAG N206-E-XL-TVP2 rulman resim 5
Price: 36.98 $
Specifications
Brand FAG
Item Number N206-E-XL-TVP2 FAG
Manufacturer Part Number 0192172180000
Also known as N206-E-TVP2
EAN 4012801174855
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 62
Width (B) MM 16
Inner (d) Inch 1.1811
Outer (D) Inch 2.4409
Width (B) Inch 0.6299
Weight (kg) 0.198 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type P - Plastic Molded Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 16
Radial Static Load Rating C0r (N) 37500
Radial Dynamic Load Rating Cr (N) 46000
Basic static load rating, radial (C 0r) "37500.0000"
Limiting speed for grease lubrication (n G Grease) 13900
Limiting speed for oil lubrication (n G Oil) 16300
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing N2..-E-TVP, with cage, single row, non-locating bearing, 0 ribs on outer ring, 2 rib on inner ring, type N2
Suffix description
E Increased Load Capacity
XL X-Life
TVP2 Solid Window Cage Made From Glass Fibre Reinforced Polyamide PA66. Roller Riding
