FAG B7304-E-T-P4S-UL

FAG B7304-E-T-P4S-UL
FAG B7304-E-T-P4S-UL rulman resim 1
FAG B7304-E-T-P4S-UL rulman resim 2
FAG B7304-E-T-P4S-UL rulman resim 3
Price: 211.36 $
Specifications
Brand FAG
Item Number B7304-E-T-P4S-UL FAG
Manufacturer Part Number 0191574520000
EAN 4026677420718
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 52
Width (B) MM 15
Inner (d) Inch 0.7874
Outer (D) Inch 2.0472
Width (B) Inch 0.5906
Weight (kg) 0.14 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
