FAG B7002-E-T-P4S-UM-L074 Image 3
Visual product photo and picture of the product.
Price: 127.99 $
Specifications
Weight and Dimensions
| Inner (d) MM |
15 |
| Outer (D) MM |
32 |
| Width (B) MM |
9 |
| Inner (d) Inch |
0.5906 |
| Outer (D) Inch |
1.2598 |
| Width (B) Inch |
0.3543 |
| Weight (kg) |
0.03 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4S Precision (Higher than P4) |
| Contact Angle |
25 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements |
| Lubrication |
Low Temperature Grease |
Data from Schaeffler (medias)
| Width (b) mm |
9 |
| Basic static load rating, radial (C 0r) |
2310 |
| Limiting speed for grease lubrication (n G Grease) |
45000 |
| Limiting speed for oil lubrication (n G Oil) |
70000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
Suffix description
| E |
25° Contact Angle |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UM |
Single Bearing, Universal, Medium Preload |
| L074 |
Isoflex NBU15 Low Temperature Grease -50 ~ 130ºC |
