FAG B7002-E-T-P4S-UM-L074

FAG B7002-E-T-P4S-UM-L074
FAG B7002-E-T-P4S-UM-L074 rulman resim 1
FAG B7002-E-T-P4S-UM-L074 rulman resim 2
FAG B7002-E-T-P4S-UM-L074 rulman resim 3
FAG B7002-E-T-P4S-UM-L074 rulman resim 4
Price: 127.99 $
Specifications
Brand FAG
Item Number B7002-E-T-P4S-UM-L074 FAG
Manufacturer Part Number 0386830320000
Also known as B7002-E-T-P4S-UM
EAN 4026677883711
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 15
Outer (D) MM 32
Width (B) MM 9
Inner (d) Inch 0.5906
Outer (D) Inch 1.2598
Width (B) Inch 0.3543
Weight (kg) 0.03 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Low Temperature Grease
Data from Schaeffler (medias)
Width (b) mm 9
Basic static load rating, radial (C 0r) 2310
Limiting speed for grease lubrication (n G Grease) 45000
Limiting speed for oil lubrication (n G Oil) 70000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
L074 Isoflex NBU15 Low Temperature Grease -50 ~ 130ºC
