FAG 7309-B-XL-TVP-UO

FAG 7309-B-XL-TVP-UO
FAG 7309-B-XL-TVP-UO rulman resim 1
FAG 7309-B-XL-TVP-UO rulman resim 2
FAG 7309-B-XL-TVP-UO rulman resim 3
FAG 7309-B-XL-TVP-UO rulman resim 4
Price: 67.18 $
Specifications
Brand FAG
Item Number 7309-B-XL-TVP-UO FAG
Manufacturer Part Number 0167260650000
Also known as 7309-B-TVP-UO
EAN 4012801283335
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 100
Width (B) MM 25
Inner (d) Inch 1.7717
Outer (D) Inch 3.937
Width (B) Inch 0.9843
Weight (kg) 0.835 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UO - Zero Clearance
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 25
Radial Static Load Rating C0r (N) 43000
Radial Dynamic Load Rating Cr (N) 65000
Basic static load rating, radial (C 0r) "43000.0000"
Limiting speed (n G) 9300
Reference speed (n u03d1r) 6500
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 73..-B-XL-TVP, single row
Suffix description
B 40° Contact Angle
XL X-Life
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
UO Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance
