FAG 7305-B-XL-JP-UO Image 3
Visual product photo and picture of the product.
Price: 48.15 $
Specifications
Weight and Dimensions
| Inner (d) MM |
25 |
| Outer (D) MM |
62 |
| Width (B) MM |
17 |
| Inner (d) Inch |
0.9843 |
| Outer (D) Inch |
2.4409 |
| Width (B) Inch |
0.6693 |
| Weight (kg) |
0.229 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| Precision |
Standard Precision |
| Contact Angle |
40 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UO - Zero Clearance |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
17 |
| Radial Static Load Rating C0r (N) |
15800 |
| Radial Dynamic Load Rating Cr (N) |
28000 |
| Basic static load rating, radial (C 0r) |
"15800.0000" |
| Limiting speed (n G) |
15800 |
| Reference speed (n u03d1r) |
9800 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 73..-B-XL-JP, single row |
Suffix description
| B |
40° Contact Angle |
| XL |
X-Life |
| JP |
Pressed Steel Cage, Rolling Element Guided |
| UO |
Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance |
