FAG 7305-B-XL-JP-UO rulman resim 1
FAG 7305-B-XL-JP-UO rulman resim 2
FAG 7305-B-XL-JP-UO rulman resim 3
FAG 7305-B-XL-JP-UO rulman resim 4
FAG 7305-B-XL-JP-UO rulman resim 5
FAG 7305-B-XL-JP-UO rulman resim 6
FAG 7305-B-XL-JP-UO rulman resim 7
Price: 48.15 $
Specifications
Brand FAG
Item Number 7305-B-XL-JP-UO FAG
Manufacturer Part Number 0191167800000
Also known as 7305-B-JP-UO
EAN 4026677734556
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 62
Width (B) MM 17
Inner (d) Inch 0.9843
Outer (D) Inch 2.4409
Width (B) Inch 0.6693
Weight (kg) 0.229 kg
Product Properties
Seal No Seal
Cage Type S - Steel or Standard Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UO - Zero Clearance
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 17
Radial Static Load Rating C0r (N) 15800
Radial Dynamic Load Rating Cr (N) 28000
Basic static load rating, radial (C 0r) "15800.0000"
Limiting speed (n G) 15800
Reference speed (n u03d1r) 9800
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 73..-B-XL-JP, single row
Suffix description
B 40° Contact Angle
XL X-Life
JP Pressed Steel Cage, Rolling Element Guided
UO Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance
