FAG 6305-2RSR-C3

FAG 6305-2RSR-C3
FAG 6305-2RSR-C3 rulman resim 1
FAG 6305-2RSR-C3 rulman resim 2
FAG 6305-2RSR-C3 rulman resim 3
FAG 6305-2RSR-C3 rulman resim 4
FAG 6305-2RSR-C3 rulman resim 5
Price: 5.59 $
Specifications
Brand FAG
Item Number 6305-2RSR-C3 FAG
Manufacturer Part Number 0167229730030
EAN 4012801064965
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 62
Width (B) MM 17
Inner (d) Inch 0.9843
Outer (D) Inch 2.4409
Width (B) Inch 0.6693
Weight (kg) 0.235 kg
Product Properties
Bore C - Cylindrical Bore
Seal 2RS - Rubber Seal on Two Sides
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 17
Radial Static Load Rating C0r (N) 11500
Radial Dynamic Load Rating Cr (N) 23800
Basic static load rating, radial (C 0r) "11500.0000"
Limiting speed (n G) 7300
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 63..-2RSR, single row, cf. DIN 625-1
Suffix description
2RSR Rubber Seals At Each Side Of The Bearing
C3 Internal Clearance Larger Than Normal
