FAG 7304-B-XL-2RS-TVP-UL

FAG 7304-B-XL-2RS-TVP-UL
FAG 7304-B-XL-2RS-TVP-UL rulman resim 1
FAG 7304-B-XL-2RS-TVP-UL rulman resim 2
FAG 7304-B-XL-2RS-TVP-UL rulman resim 3
FAG 7304-B-XL-2RS-TVP-UL rulman resim 4
Price: 111.26 $
Specifications
Brand FAG
Item Number 7304-B-XL-2RS-TVP-UL FAG
Manufacturer Part Number 0558601760000
Also known as 7304-B-2RS-TVP-UL
EAN 4054372837340
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 52
Width (B) MM 15
Inner (d) Inch 0.7874
Outer (D) Inch 2.0472
Width (B) Inch 0.5906
Weight (kg) 0.146 kg
Product Properties
Seal 2RS - Rubber Seal on Two Sides
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 15
Radial Static Load Rating C0r (N) 11100
Radial Dynamic Load Rating Cr (N) 20400
Basic static load rating, radial (C 0r) "11100.0000"
Limiting speed (n G) 8600
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 73..-B-2RS, main dimensions to DIN 628-1, contact angle a = 40°, lip seals on both sides
Suffix description
B 40° Contact Angle
XL X-Life
2RS Rubber Seals At Each Side Of The Bearing
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
UL Single Bearing, Universal, Light Preload
