FAG 7214-B-XL-MP

FAG 7214-B-XL-MP
FAG 7214-B-XL-MP rulman resim 1
FAG 7214-B-XL-MP rulman resim 2
FAG 7214-B-XL-MP rulman resim 3
FAG 7214-B-XL-MP rulman resim 4
Price: 139.35 $
Specifications
Brand FAG
Item Number 7214-B-XL-MP FAG
Manufacturer Part Number 0167254170000
Also known as 7214-B-MP
EAN 4012801282598
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 70
Outer (D) MM 125
Width (B) MM 24
Inner (d) Inch 2.7559
Outer (D) Inch 4.9213
Width (B) Inch 0.9449
Weight (kg) 1.188 kg
Product Properties
Seal No Seal
Cage Type M - Brass Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 24
Radial Static Load Rating C0r (N) 58000
Radial Dynamic Load Rating Cr (N) 71000
Basic static load rating, radial (C 0r) "58000.0000"
Limiting speed (n G) 9400
Reference speed (n u03d1r) 5500
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
