FAG 7214-B-XL-JP-UA

FAG 7214-B-XL-JP-UA
FAG 7214-B-XL-JP-UA rulman resim 1
FAG 7214-B-XL-JP-UA rulman resim 2
FAG 7214-B-XL-JP-UA rulman resim 3
FAG 7214-B-XL-JP-UA rulman resim 4
Price: 116.52 $
Specifications
Brand FAG
Item Number 7214-B-XL-JP-UA FAG
Manufacturer Part Number 0191153850000
Also known as 7214-B-JP-UA
EAN 4026677690340
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 70
Outer (D) MM 125
Width (B) MM 24
Inner (d) Inch 2.7559
Outer (D) Inch 4.9213
Width (B) Inch 0.9449
Weight (kg) 1.14 kg
Product Properties
Seal No Seal
Cage Type S - Steel or Standard Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 24
Radial Static Load Rating C0r (N) 62000
Radial Dynamic Load Rating Cr (N) 74000
Basic static load rating, radial (C 0r) "62000.0000"
Limiting speed (n G) 7200
Reference speed (n u03d1r) 5400
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
JP Pressed Steel Cage, Rolling Element Guided
UA Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance
