FAG 7214-B-XL-2RS-TVP

FAG 7214-B-XL-2RS-TVP
FAG 7214-B-XL-2RS-TVP rulman resim 1
FAG 7214-B-XL-2RS-TVP rulman resim 2
FAG 7214-B-XL-2RS-TVP rulman resim 3
FAG 7214-B-XL-2RS-TVP rulman resim 4
Price: 530.43 $
Specifications
Brand FAG
Item Number 7214-B-XL-2RS-TVP FAG
Manufacturer Part Number 0390886930000
Also known as 7214-B-2RS-TVP
EAN 4012802156812
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 70
Outer (D) MM 125
Width (B) MM 24
Inner (d) Inch 2.7559
Outer (D) Inch 4.9213
Width (B) Inch 0.9449
Weight (kg) 1.092 kg
Product Properties
Seal 2RS - Rubber Seal on Two Sides
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 24
Radial Static Load Rating C0r (N) 62000
Radial Dynamic Load Rating Cr (N) 74000
Basic static load rating, radial (C 0r) "62000.0000"
Limiting speed (n G) 3000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B-2RS, main dimensions to DIN 628-1, contact angle a = 40°, lip seals on both sides
Suffix description
B 40° Contact Angle
XL X-Life
2RS Rubber Seals At Each Side Of The Bearing
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
