FAG 7209-B-XL-MP-UB Image 2
Visual product photo and picture of the product.
Price: 75.84 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
85 |
| Width (B) MM |
19 |
| Weight (kg) |
0.43 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| Precision |
Standard Precision |
| Contact Angle |
40 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UB (only use FAG) - Small Axial Clearance |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
19 |
| Radial Static Load Rating C0r (N) |
27000 |
| Radial Dynamic Load Rating Cr (N) |
40000 |
| Basic static load rating, radial (C 0r) |
"27000.0000" |
| Limiting speed (n G) |
14300 |
| Reference speed (n u03d1r) |
8000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40° |
Suffix description
| B |
40° Contact Angle |
| XL |
X-Life |
| MP |
Machined Brass Cage, Window Type, Rolling Element Riding |
| UB |
Axial Clearance/Preload, Universal Bearing, Small Axial Clearance |
