FAG 7209-B-XL-MP-UB

FAG 7209-B-XL-MP-UB
FAG 7209-B-XL-MP-UB rulman resim 1
FAG 7209-B-XL-MP-UB rulman resim 2
FAG 7209-B-XL-MP-UB rulman resim 3
Price: 75.84 $
Specifications
Brand FAG
Item Number 7209-B-XL-MP-UB FAG
Manufacturer Part Number 0893828540000
Also known as 7209-B-MP-UB
EAN 4054369524154
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Weight (kg) 0.43 kg
Product Properties
Seal No Seal
Cage Type M - Brass Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UB (only use FAG) - Small Axial Clearance
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 19
Radial Static Load Rating C0r (N) 27000
Radial Dynamic Load Rating Cr (N) 40000
Basic static load rating, radial (C 0r) "27000.0000"
Limiting speed (n G) 14300
Reference speed (n u03d1r) 8000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
UB Axial Clearance/Preload, Universal Bearing, Small Axial Clearance
