FAG 6209-C-2Z-L100-C3

FAG 6209-C-2Z-L100-C3
FAG 6209-C-2Z-L100-C3 rulman resim 1
FAG 6209-C-2Z-L100-C3 rulman resim 2
FAG 6209-C-2Z-L100-C3 rulman resim 3
FAG 6209-C-2Z-L100-C3 rulman resim 4
Price: 21.63 $
Specifications
Brand FAG
Item Number 6209-C-2Z-L100-C3 FAG
Manufacturer Part Number 0892768330030
Also known as 6209-2Z-L100-C3
EAN 4054371579920
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Inner (d) Inch 1.7717
Outer (D) Inch 3.3465
Width (B) Inch 0.748
Weight (kg) 0.413 kg
Product Properties
Bore C - Cylindrical Bore
Seal ZZ/2Z - Steel Seal on Two Sides
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Higher and Lower Temperature Grease
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 19
Radial Static Load Rating C0r (N) 20300
Radial Dynamic Load Rating Cr (N) 33500
Basic static load rating, radial (C 0r) "20300.0000"
Limiting speed (n G) 10800
Reference speed (n u03d1r) 9900
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 62..-C-2Z, single row, cf. DIN 625-1
Suffix description
C Deep Groove Ball Bearings Of Generation C, Modified Internal Construction
2Z Gap Seals On Both Sides
L100 High/Low Temperature Grease -40ºC/+160ºC
C3 Internal Clearance Larger Than Normal
