FAG 6209-C-2Z-L100-C3 Image 2
Visual product photo and picture of the product.
Price: 21.63 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
85 |
| Width (B) MM |
19 |
| Inner (d) Inch |
1.7717 |
| Outer (D) Inch |
3.3465 |
| Width (B) Inch |
0.748 |
| Weight (kg) |
0.413 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
ZZ/2Z - Steel Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Higher and Lower Temperature Grease |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
19 |
| Radial Static Load Rating C0r (N) |
20300 |
| Radial Dynamic Load Rating Cr (N) |
33500 |
| Basic static load rating, radial (C 0r) |
"20300.0000" |
| Limiting speed (n G) |
10800 |
| Reference speed (n u03d1r) |
9900 |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Deep groove ball bearing 62..-C-2Z, single row, cf. DIN 625-1 |
Suffix description
| C |
Deep Groove Ball Bearings Of Generation C, Modified Internal Construction |
| 2Z |
Gap Seals On Both Sides |
| L100 |
High/Low Temperature Grease -40ºC/+160ºC |
| C3 |
Internal Clearance Larger Than Normal |
