FAG 7206-B-XL-TVP-P5-UO

FAG 7206-B-XL-TVP-P5-UO
FAG 7206-B-XL-TVP-P5-UO rulman resim 1
FAG 7206-B-XL-TVP-P5-UO rulman resim 2
FAG 7206-B-XL-TVP-P5-UO rulman resim 3
FAG 7206-B-XL-TVP-P5-UO rulman resim 4
Price: 80.10 $
Specifications
Brand FAG
Item Number 7206-B-XL-TVP-P5-UO FAG
Manufacturer Part Number 0167251150000
Also known as 7206-B-TVP-P5-UO
EAN 4012801165938
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 62
Width (B) MM 16
Inner (d) Inch 1.1811
Outer (D) Inch 2.4409
Width (B) Inch 0.6299
Weight (kg) 0.201 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision P5 Precision (Higher than P6)
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UO - Zero Clearance
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 16
Radial Static Load Rating C0r (N) 14100
Radial Dynamic Load Rating Cr (N) 23100
Basic static load rating, radial (C 0r) "14100.0000"
Limiting speed (n G) 15800
Reference speed (n u03d1r) 11200
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 72..-B-XL-TVP, single row
Suffix description
B 40° Contact Angle
XL X-Life
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
P5 Dimensional And Running Accuracy To ISO Tolerance Class 5
UO Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance
