FAG 7206-B-XL-2RS-TVP-UL

FAG 7206-B-XL-2RS-TVP-UL
FAG 7206-B-XL-2RS-TVP-UL rulman resim 1
FAG 7206-B-XL-2RS-TVP-UL rulman resim 2
FAG 7206-B-XL-2RS-TVP-UL rulman resim 3
FAG 7206-B-XL-2RS-TVP-UL rulman resim 4
Price: 124.78 $
Specifications
Brand FAG
Item Number 7206-B-XL-2RS-TVP-UL FAG
Manufacturer Part Number 0613505400000
Also known as 7206-B-2RS-TVP-UL
EAN 4012802347616
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 62
Width (B) MM 16
Inner (d) Inch 1.1811
Outer (D) Inch 2.4409
Width (B) Inch 0.6299
Weight (kg) 0.208 kg
Product Properties
Seal 2RS - Rubber Seal on Two Sides
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 16
Radial Static Load Rating C0r (N) 14100
Radial Dynamic Load Rating Cr (N) 23100
Basic static load rating, radial (C 0r) "14100.0000"
Limiting speed (n G) 6500
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B-2RS, main dimensions to DIN 628-1, contact angle a = 40°, lip seals on both sides
Suffix description
B 40° Contact Angle
XL X-Life
2RS Rubber Seals At Each Side Of The Bearing
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
UL Single Bearing, Universal, Light Preload
