FAG 3802-B-2RSR-TVH-HLC Image 2
Visual product photo and picture of the product.
Price: 21.87 $
Specifications
Weight and Dimensions
| Inner (d) MM |
15 |
| Outer (D) MM |
24 |
| Width (B) MM |
7 |
| Inner (d) Inch |
0.5906 |
| Outer (D) Inch |
0.9449 |
| Width (B) Inch |
0.2756 |
| Weight (kg) |
0.009 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
2RS - Rubber Seal on Two Sides |
| Cage Type |
P - Plastic Molded Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
7 |
| Radial Static Load Rating C0r (N) |
1920 |
| Radial Dynamic Load Rating Cr (N) |
2380 |
| Basic static load rating, radial (C 0r) |
"1920.0000" |
| Limiting speed (n G) |
14700 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearings 38..-B-2RS, Double row design, lip seals on both sides, contact angle a = 25° |
Suffix description
| B |
Internal Design Modification |
| 2RSR |
Seal At Each Side Of The Bearing |
| TVH |
Moulded Polyamide Cage Snap-Type, Rolling Element Riding |
| HLC |
Factory Location Code, No Additional Meaning, Can Be Used As Standard |
