FAG 3802-B-2RSR-TVH-HLC
Price: 21.87 $
Specifications
| Brand | FAG |
| Item Number | 3802-B-2RSR-TVH-HLC FAG |
| Manufacturer Part Number | 0725293000000 |
| Also known as |
3802-B-2RSR-TVH |
| EAN | 4012802774450 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 15 |
| Outer (D) MM | 24 |
| Width (B) MM | 7 |
| Inner (d) Inch | 0.5906 |
| Outer (D) Inch | 0.9449 |
| Width (B) Inch | 0.2756 |
| Weight (kg) | 0.009 kg |
| Bore | C - Cylindrical Bore |
| Seal | 2RS - Rubber Seal on Two Sides |
| Cage Type | P - Plastic Molded Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Standard |
| Width (b) mm | 7 |
| Radial Static Load Rating C0r (N) | 1920 |
| Radial Dynamic Load Rating Cr (N) | 2380 |
| Basic static load rating, radial (C 0r) | "1920.0000" |
| Limiting speed (n G) | 14700 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearings 38..-B-2RS, Double row design, lip seals on both sides, contact angle a = 25° |
| B | Internal Design Modification |
| 2RSR | Seal At Each Side Of The Bearing |
| TVH | Moulded Polyamide Cage Snap-Type, Rolling Element Riding |
| HLC | Factory Location Code, No Additional Meaning, Can Be Used As Standard |
FAG 63802-2Z-HLC
0.01 kg
15x24x7 mm
FAG 63802-2RSR-HLC
0.01 kg
15x24x7 mm
INA 63802-2Z-HLC
0.01 kg
15x24x7 mm
INA 63802 2RS
0.01 kg
15x24x7 mm
AKN 63802ZZ
0.01 kg
15x24x7 mm
AKN 63802 2RS
0.01 kg
15x24x7 mm
EZO 63802ZZ
0.01 kg
15x24x7 mm
EZO 63802 2RS
0.01 kg
15x24x7 mm
ZEN 63802 2RS
0.01 kg
15x24x7 mm
Neutral 63802 2RS
0.01 kg
15x24x7 mm
INA 63802 2Z
0.01 kg
15x24x7 mm
INA 63802-2RSR-HLC
0.01 kg
15x24x7 mm
Japanese Origin 63802ZZ
0.01 kg
15x24x7 mm
FSY (China) 63802
0.01 kg
15x24x7 mm
FSY (China) 63802 2RS
0.01 kg
15x24x7 mm
FSY (China) 63802C3
0.01 kg
15x24x7 mm
FSY (China) 63802ZZ C3
0.01 kg
15x24x7 mm
China 63802 2RS
0.01 kg
15x24x7 mm
EZO 63802H 2RS
0.01 kg
15x24x7 mm
FAG 3802-B-2Z-TVH-HLC
0.009 kg
15x24x7 mm
INA 3802-2RS-HLC
0.009 kg
15x24x7 mm
INA 3802-2Z-HLC
0.009 kg
15x24x7 mm
INA 3802ZZ
0.009 kg
15x24x7 mm
INA 3802-2Z
0.009 kg
15x24x7 mm
INA 3802-2RS
0.009 kg
15x24x7 mm
INA 3802 2RS
0.009 kg
15x24x7 mm
FAG 3802-B-2Z-TVH
0.009 kg
15x24x7 mm
INA 3802 2RS HLC
0.009 kg
15x24x7 mm
FAG 3802-2Z-HLC
0.009 kg
15x24x7 mm
FAG 3802-B-2RSR-TVH
0.009 kg
15x24x7 mm
INA 3802-B-2RSR-TVH-HLC
0.009 kg
15x24x7 mm
WIB 3802 2RS T9H
0.009 kg
15x24x7 mm
Neutral 3802 2RS
0.009 kg
15x24x7 mm
Neutral 3802ZZ
0.009 kg
15x24x7 mm
