FAG 3314-C3 Image 2
Visual product photo and picture of the product.
Price: 291.52 $
Specifications
Weight and Dimensions
| Inner (d) MM |
70 |
| Outer (D) MM |
150 |
| Width (B) MM |
63,5 |
| Inner (d) Inch |
2.7559 |
| Outer (D) Inch |
5.9055 |
| Width (B) Inch |
2.5 |
| Weight (kg) |
4.89 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
63,5 |
| Radial Static Load Rating C0r (N) |
176000 |
| Radial Dynamic Load Rating Cr (N) |
167000 |
| Basic static load rating, radial (C 0r) |
"176000.0000" |
| Limiting speed (n G) |
4750 |
| Reference speed (n u03d1r) |
4500 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearings 33, main dimensions to DIN 628-3, double row, with filling slots, contact angle a = 35° |
Suffix description
| C3 |
Internal Clearance Larger Than Normal |
