FAG 3314-C3
Price: 291.52 $
Specifications
| Brand | FAG |
| Item Number | 3314-C3 FAG |
| Manufacturer Part Number | 0167138690030 |
| EAN | 4012801271271 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 70 |
| Outer (D) MM | 150 |
| Width (B) MM | 63,5 |
| Inner (d) Inch | 2.7559 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 2.5 |
| Weight (kg) | 4.89 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Standard |
| Width (b) mm | 63,5 |
| Radial Static Load Rating C0r (N) | 176000 |
| Radial Dynamic Load Rating Cr (N) | 167000 |
| Basic static load rating, radial (C 0r) | "176000.0000" |
| Limiting speed (n G) | 4750 |
| Reference speed (n u03d1r) | 4500 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearings 33, main dimensions to DIN 628-3, double row, with filling slots, contact angle a = 35° |
| C3 | Internal Clearance Larger Than Normal |
Fafnir W314PP FS55627
3.883 kg
70x150x63,5 mm
Torrington W314PP FS55627
3.883 kg
70x150x63,5 mm
NTN 63314LLB
4.763 kg
70x150x63,5 mm
FAG 3314-BD-XL-2Z-TVH-L140-C3
4.89 kg
70x150x63,5 mm
FAG 3314-DA-MA
5.55 kg
70x150x63,5 mm
FAG 3314-BD-XL-C3
4.89 kg
70x150x63,5 mm
INA 3314-2RS
4.89 kg
70x150x63,5 mm
FAG 3314-C4
4.89 kg
70x150x63,5 mm
FAG 3314-BD-XL
4.89 kg
70x150x63,5 mm
FAG 3314-BD-XL-2HRS-TVH
4.54 kg
70x150x63,5 mm
SKF 3314A/C3
4.89 kg
70x150x63,5 mm
MRC/Marlin Rockwell 5314G
4.89 kg
70x150x63,5 mm
SKF 3314A-2ZTN9/C3VT113
4.89 kg
70x150x63,5 mm
NSK 3314JC3
4.89 kg
70x150x63,5 mm
Fafnir 5314KGC3
4.89 kg
70x150x63,5 mm
UBC 5314-2RS
4.89 kg
70x150x63,5 mm
KFB Clarfeld 3314
4.89 kg
70x150x63,5 mm
FAG 3314-BD-XL-TVH
4.89 kg
70x150x63,5 mm
INA 3314 2RS
4.89 kg
70x150x63,5 mm
FAG 3314B-TVH
4.89 kg
70x150x63,5 mm
FAG 3314-B-TVH
4.89 kg
70x150x63,5 mm
FAG 3314-DA
5.55 kg
70x150x63,5 mm
FAG 3314-B-TVH-C3
4.89 kg
70x150x63,5 mm
FAG 3314-BD-2Z-TVH-L140-C3
4.89 kg
70x150x63,5 mm
FAG 3314-C3
4.89 kg
70x150x63,5 mm
FAG 3314-BD-XL-TVH-C3
4.89 kg
70x150x63,5 mm
SKF 3314/C4
4.89 kg
70x150x63,5 mm
