FAG 32022-X-XL-DF-A90-130 Image 4
Visual product photo and picture of the product.
Price: 363.71 $
Specifications
Weight and Dimensions
| Inner (d) MM |
110 |
| Outer (D) MM |
170 |
| Width (B) MM |
76 |
| Inner (d) Inch |
4.3307 |
| Outer (D) Inch |
6.6929 |
| Width (B) Inch |
2.9921 |
| Weight (kg) |
6.31 kg
|
Product Properties
| Tapered Roller Pair Internal Play |
90-130µm |
Data from Schaeffler (medias)
| Inner ring total width (2B) mm |
76 |
| Radial Static Load Rating C0r (N) |
790000 |
| Radial Dynamic Load Rating Cr (N) |
490000 |
| Basic static load rating, radial (C 0r) |
"790000.0000" |
| Limiting speed (n G) |
4350 |
| Outer ring total width (2T) mm |
76 |
| Thermal speed rating (n u03d1r) |
2440 |
| ECLASS number |
23-05-09-10 |
| ECLASS2 number |
23-05-09-10 |
| Medias description |
Tapered roller bearing set 320..-X-XL-DF, X-arrangement |
Suffix description
| X |
External Dimensions Matched To International Standards |
| XL |
X-Life |
| DF |
Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A90-130 |
Axial Clearance In µm |
