FAG 32022-X-XL-DF-A90-130

Specifications

Brand	FAG
Item Number	32022-X-XL-DF-A90-130 FAG
Manufacturer Part Number	0837046554082
Also known as	32022-X-DF-A90-130
EAN	4064328627192
Category	Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

Inner (d) MM	110
Outer (D) MM	170
Width (B) MM	76
Inner (d) Inch	4.3307
Outer (D) Inch	6.6929
Width (B) Inch	2.9921
Weight (kg)	6.31 kg

Product Properties

Tapered Roller Pair Internal Play

90-130µm

Data from Schaeffler (medias)

Inner ring total width (2B) mm	76
Radial Static Load Rating C0r (N)	790000
Radial Dynamic Load Rating Cr (N)	490000
Basic static load rating, radial (C 0r)	"790000.0000"
Limiting speed (n G)	4350
Outer ring total width (2T) mm	76
Thermal speed rating (n u03d1r)	2440
ECLASS number	23-05-09-10
ECLASS2 number	23-05-09-10
Medias description	Tapered roller bearing set 320..-X-XL-DF, X-arrangement

Suffix description

X	External Dimensions Matched To International Standards
XL	X-Life
DF	Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
A90-130	Axial Clearance In µm
