FAG 31313-XL-DF-A120-160 Image 3
Visual product photo and picture of the product.
Price: 338.18 $
Specifications
Weight and Dimensions
| Inner (d) MM |
65 |
| Outer (D) MM |
140 |
| Width (B) MM |
72 |
| Inner (d) Inch |
2.5591 |
| Outer (D) Inch |
5.5118 |
| Width (B) Inch |
2.8346 |
| Weight (kg) |
5.05 kg
|
Product Properties
| Tapered Roller Pair Internal Play |
120-160µm |
Data from Schaeffler (medias)
| Inner ring total width (2B) mm |
66 |
| Radial Static Load Rating C0r (N) |
375000 |
| Radial Dynamic Load Rating Cr (N) |
330000 |
| Basic static load rating, radial (C 0r) |
"375000.0000" |
| Limiting speed (n G) |
5500 |
| Outer ring total width (2T) mm |
72 |
| Thermal speed rating (n u03d1r) |
3650 |
| ECLASS number |
23-05-09-10 |
| ECLASS2 number |
23-05-09-10 |
| Medias description |
Tapered roller bearing set 313..-XL-DF, X-arrangement |
Suffix description
| XL |
X-Life |
| DF |
Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings |
| A120-160 |
Axial Clearance In µm |
